Garmin GPSMAP 9217 Multifunction Display
$4,354.00
Garmin GPSMAP 9217 Multifunction Display is a 17.25-inch 4K IPS helm display with Mini LED local dimming, preloaded Garmin Navionics+ mapping, and Garmin BlueNet networking. It is built for larger glass helm layouts that need chart detail, screen space, and fast system response.
Overview Garmin GPSMAP 9217 Multifunction Display
Garmin GPSMAP 9217 Multifunction Display is a large-format 17.25-inch helm display designed for vessels that want a 4K primary screen with integrated chart coverage. The IPS panel uses 3840 x 2160 resolution with Mini LED local dimming, giving more room for charting, split-screen layouts, radar, and networked data.
This version includes preloaded Garmin Navionics+ mapping and uses the updated Garmin platform listed in the source as 7 times faster than previous generations. Garmin BlueNet enables high-speed network communication, while the built-in 10 Hz multi-band GNSS receiver and broad connectivity options support larger integrated helm systems.
Key Features
- 17.25-inch 4K IPS display: Provides a large working surface for chart navigation and multi-window operation.
- Mini LED local dimming: Helps improve contrast and visibility for chart and system data across changing light conditions.
- Preloaded Garmin Navionics+ mapping: Adds onboard chart coverage for immediate route planning and navigation use.
- 7x faster processing platform: Supports quicker response during chart redraws, zooming, and general system control.
- Garmin BlueNet networking: Supports fast sharing of compatible radar, cameras, displays, and other helm data.
Applications
Well suited to larger cruising, offshore, and sportfishing helms that need one large display with charting already included.
A strong choice for Garmin glass helm layouts where high-resolution screen area and fast networking matter across multiple devices.
Specifications
| Display size | 17.25 inches diagonal |
| Display resolution | 4K 3840 x 2160 pixels |
| Processor speed | 7x faster than previous generations |
| Display type | IPS with Mini LED (local dimming) |
| Mapping | Preloaded Garmin Navionics+ |
| Networking | Garmin BlueNet (gigabit speeds) |
| Internal GPS | 10 Hz multi-band / multi-constellation |
| Connectivity | NMEA 2000, J1939, USB-C, Wi-Fi, ANT |
| Waterproof rating | IPX7 |
| Weight | 13.0 lbs (5.9 kg) |
What’s Included
- Garmin GPSMAP 9217 Premium Chartplotter
- Garmin Navionics+™ Mapping (Preloaded)
- Power Cable and NMEA 2000® T-connector
- NMEA 2000 Backbone/Drop Cable (2 meters)
- Flush Mount Kit and Protective Cover
- Trim Piece Snap Covers
- Comprehensive Documentation Pack
Frequently Asked Questions About Garmin GPSMAP 9217 Multifunction Display
What kind of helm setup is Garmin GPSMAP 9217 Multifunction Display built for?
Garmin GPSMAP 9217 Multifunction Display is designed for skippers who want chart navigation and sailing data in one helm display. It combines its 17.25-inch format with a 10 Hz GPS/GNSS receiver, making it useful for offshore or blue-water passages.
How does this chartplotter balance visibility and operation underway?
This chartplotter uses a 17.25-inch screen and IPS display technology to keep charts and data readable through normal helm use. Its interface is meant to keep common tasks straightforward when the operator needs quick access to charts and data.
How network-ready is this chartplotter for a modern helm?
This chartplotter supports NMEA 2000 and Wi-Fi. That helps the unit exchange navigation, instrument, and sensor data across the boat. It is intended to work as part of a broader onboard electronics setup rather than in isolation.
Which sailing styles or helm layouts suit this chartplotter?
This chartplotter is aimed at owners who want a capable helm display matched to real onboard navigation and monitoring needs. It suits installations where visibility, integration, and quick access to data matter more than unnecessary complexity.
