Raymarine Axiom 2 9 Multifunction Display
$1,039.00
Raymarine Axiom 2 9 Multifunction Display is a 9-inch helm display with a 6-core processor, HydroTough IPS touchscreen, and preloaded LightHouse North America charts. It combines 10 Hz GNSS, 64 GB SSD storage, and RayNet-ready connectivity in a mid-size format.
Overview Raymarine Axiom 2 9 Multifunction Display
Raymarine Axiom 2 9 Multifunction Display is a 9-inch helm display built for operators who want more screen area than a compact unit while keeping installation size manageable. The HydroTough IPS display uses a 1280 x 720 panel with 1,500 nits of brightness, and the source data lists a 6-core marine processor for smooth chart handling and responsive operation.
This model includes LightHouse North America chart coverage and is designed to sit at the center of a connected Raymarine helm. It combines RayNet Gigabit Ethernet, Wi-Fi, Bluetooth 4.0, 64 GB of internal SSD storage, and a 10 Hz GPS / GLONASS / BeiDou receiver for navigation and broader system integration.
Key Features
- 9-inch HydroTough IPS display: Balances compact installation with enough room for chart detail and split-screen viewing.
- 6-core marine processor: Helps keep the interface responsive during chart movement and connected system use.
- 64 GB internal SSD storage: Provides onboard capacity for chart content, recordings, and user data.
- Preloaded LightHouse North America charts: Adds chart coverage for quicker deployment after installation.
- RayNet and 10 Hz GNSS support: Combines network expansion with frequent position updates for smoother navigation data.
Applications
A good match for mid-size center consoles, cruising boats, and mixed fishing or navigation setups that want a 9-inch primary display.
Useful where operators need one touchscreen for charting, network accessories, and LightHouse OS control without moving to a larger 12-inch unit.
Specifications
| Display size | 9.0-inch diagonal IPS display |
| Resolution | HD 1280 x 720 pixels |
| Brightness | 1,500 nits (sunlight readable) |
| Processor | High-performance 6-core marine CPU |
| Internal storage | 64 GB solid state (SSD) |
| Networking | RayNet Gigabit Ethernet, Wi-Fi, Bluetooth 4.0 |
| GNSS receiver | 10 Hz GPS / GLONASS / BeiDou |
| Voltage range | 8 V to 16 V DC (12 V nominal) |
| Waterproof rating | IPX6 and IPX7 |
| Warranty | 3-year manufacturer warranty (upon registration) |
What’s Included
- Raymarine Axiom 2 9 Multifunction Display
- LightHouse North America Chart (Preloaded/microSD)
- Trunnion Mount Kit with Knobs
- Flush Mount Gasket and Mounting Hardware
- Power/NMEA 2000 Cable (1.5 meters)
- Protective Suncover and Documentation Pack
Frequently Asked Questions About Raymarine Axiom 2 9 Multifunction Display
What kind of helm setup is Raymarine Axiom 2 9 Multifunction Display built for?
Raymarine Axiom 2 9 Multifunction Display is designed to bring key navigation and onboard data together on a single helm screen. With its 9-inch screen and fast chart and page handling, it suits helm navigation and system monitoring.
How does this marine display support fast access to navigation data?
This marine display uses a 9-inch screen and IPS display technology to keep charts and data readable in bright cockpit conditions. It also offers touchscreen control, so the operator can choose the control method that best fits the conditions.
How network-ready is this marine display for a modern helm?
This marine display supports NMEA 2000, Ethernet, Wi-Fi, and Bluetooth, plus microSD storage and onboard charting. That gives crews a cleaner way to manage charts and connected data from the helm.
Which helm layouts are a good fit for this marine display?
This marine display is aimed at owners who want a capable helm display matched to real onboard navigation and monitoring needs. It suits installations where visibility, integration, and quick access to data matter more than unnecessary complexity.
