Simrad NSS 4-16 Multifunction Display
$3,769.00
Simrad NSS 4-16 Multifunction Display is a 16-inch multifunction display designed for integrated helm control, combining 16-inch display with Full HD 1920 x 1080 pixels, an 8-core processor, NMEA 2000, GbE Ethernet, Wi-Fi 5, plus Hybrid (Touch, Rotary, Keypad).
Overview Simrad NSS 4-16 Multifunction Display
Simrad NSS 4-16 Multifunction Display is a multifunction display designed to act as a central helm screen for navigation, radar, cameras, and connected vessel systems. It combines 16-inch, Full HD 1920 x 1080 pixels, Qualcomm® 8-Core (High-Speed), plus Hybrid (Touch, Rotary, Keypad).
The Simrad NSS 4-16 is a well-suited option for captains of large center consoles and sportfishing yachts where visual scale and tactile reliability are paramount. While a wet touchscreen might struggle, the captain can rely on the robust rotary dial and keypad to accurately adjust the HALO radar gain or mark a critical waypoint.
Key Features
- Display and visibility: 16-inch, Full HD 1920 x 1080 pixels, >1200 nits (Sunlight Readable). This supports clear chart viewing and better readability at the helm.
- Processing platform: Qualcomm® 8-Core (High-Speed). It helps keep menu response, chart redraws, and split-screen operation smooth.
- User interface: Hybrid (Touch, Rotary, Keypad). This gives the operator direct access to navigation functions and connected system control from the main screen.
- Networking and integration: NMEA 2000, GbE Ethernet, Wi-Fi 5. Compatible networking helps the unit share charts, radar, sensors, cameras, and other onboard data where supported.
- Position data: 10 Hz (GPS, GLONASS, Galileo, Beidou). This supports accurate vessel positioning and update speed for navigation tasks.
Applications
The Simrad NSS 4-16 is a well-suited option for captains of large center consoles and sportfishing yachts where visual scale and tactile reliability are paramount. While a wet touchscreen might struggle, the captain can rely on the robust rotary dial and keypad to accurately adjust the HALO radar gain or mark a critical waypoint.
Because the 8-core processor is so fast, the 16-inch display can run a massive 4-way split screen—charts, radar, engine telemetry, and live camera feeds—without any stutter, providing the situational awareness needed for safe, high-speed transit.
Specifications
| Display Size | 16.0 inches SolarMax™ IPS |
| Resolution | Full HD 1920 x 1080 pixels |
| Processor | Qualcomm® 8-Core (High-Speed) |
| Brightness | >1200 nits (Sunlight Readable) |
| Control Type | Hybrid (Touch, Rotary, Keypad) |
| Networking | NMEA 2000, GbE Ethernet, Wi-Fi 5 |
| GPS Update Rate | 10 Hz (GPS, GLONASS, Galileo, Beidou) |
| Waterproof Rating | IPX6 and IPX7 Standards |
| Supply Voltage | 12/24 V DC (10 – 31.2 V DC) |
| Warranty | 2-Year Limited manufacturer warranty |
What’s Included
- 1x Simrad NSS 4-16 16-inch Multifunction Display
- 1x Suncover for 16″ Display
- 1x Rear Mount Brackets and Hardware
- 1x Power Cable (4-pin)
- 1x Edge Trim pieces (Top/Bottom and Sides)
- 1x Comprehensive Installation and Operation Documentation
Frequently Asked Questions About Simrad NSS 4-16 Multifunction Display
Why would a skipper choose Simrad NSS 4-16 Multifunction Display?
Simrad NSS 4-16 Multifunction Display is designed to bring key navigation and onboard data together on a single helm screen. With its 16-inch screen and fast chart and page handling, it suits yachts and sailboats.
What helps this marine display stay readable and usable underway?
This marine display uses a 16-inch screen and SolarMAX display technology to keep charts and data readable in bright cockpit conditions. It also offers touchscreen control, a rotary dial, and keypad operation, so the operator can choose the control method that best fits the conditions.
What types of electronics links does this marine display provide?
This marine display supports NMEA 2000, Ethernet, and Wi-Fi. That gives crews a cleaner way to manage charts and connected data from the helm. It is intended to work as part of a broader onboard electronics setup rather than in isolation.
Where does this marine display make the most sense on board?
This marine display is aimed at owners who want a capable helm display matched to real onboard navigation and monitoring needs. It suits installations where visibility, integration, and quick access to data matter more than unnecessary complexity.
