Phasor K3-7.0pmg 7.0 kW Marine Generator 120/240V
$6,858.00
Phasor K3-7.0pmg 7.0 kW Marine Generator 120/240V is an ignition protected diesel unit with a Kubota D902-E4B engine, low 1800 RPM operation, safety shutdown protection, and an included spare parts kit. It offers clearly stated output, compact dimensions, and practical service components for marine buyers comparing verified generator specifications.
Overview Phasor K3-7.0pmg 7.0 kW Marine Generator 120/240V
Phasor K3-7.0pmg 7.0 kW Marine Generator 120/240V is an ignition protected diesel marine generator built around the Kubota D902-E4B engine and low 1800 RPM operating speed. This model delivers a stated 7.0 kW at 60 Hz and 5.5 kW at 50 Hz, with 120/240V output and listed 58/29 amp output. For buyers comparing marine generators by verified data, this unit stands out for its clearly defined engine, output, protection features, and included service kit components.
Key Features of Phasor K3-7.0pmg 7.0 kW Marine Generator 120/240V
- Kubota D902-E4B diesel engine with three-cylinder configuration.
- 7.0 kW rating at 60 Hz and 5.5 kW rating at 50 Hz.
- 120/240V output with listed 58/29 amp specification.
- Low 1800 RPM operating speed.
- Ignition protected design for applications where that specification is required.
- Safety shutdown system for high coolant temperature or low lube oil pressure.
- Single series circuit control system with no printed circuit boards and tinned wiring.
- Fresh water double pass heat exchanger with removable integral cupro-nickel heat exchanger core.
- Water cooled exhaust manifold, stainless steel exhaust elbow cast, and gear driven raw water pump.
- Main line circuit breaker, spin-on lube and fuel filters, secondary 5 micron fuel filter, and self bleed fuel system.
- Electric fuel transfer pump, forged brass oil drain valve with safety lock, and belt guard.
Applications
This model is suitable for buyers looking for a diesel marine generator with clearly stated 7.0 kW output at 60 Hz, 120/240V output, and ignition protection. It is also relevant for replacement projects where the engine model, operating speed, line sizes, and service-related components are important selection points during specification review.
Why Choose This Marine Generator
This generator gives buyers a straightforward specification set without relying on vague marketing claims. The confirmed details include the Kubota engine model, output ratings, voltage, operating speed, safety shutdown protection, and listed spare parts kit contents. The included service items add practical value, while the 5 year limited warranty provides a clear and verified ownership detail for product comparison.
Product Specifications
| Feature | Details |
|---|---|
| Brand | Phasor |
| Model | K3-7.0pmg |
| Product Type | Diesel Marine Generator |
| Engine Model | Kubota D902-E4B |
| Number of Cylinders | 3 |
| Cubic Inch Displacement | 54.8 |
| KW Rating at 60 Hz | 7.0 kW |
| KW Rating at 50 Hz | 5.5 kW |
| Fuel Consumption | Full Load 0.61 gal/hr; Half Load 0.32 gal/hr |
| Electric End | Coliseum |
| Bore x Stroke | 2.83" x 2.90" |
| Weight | 344 lbs. |
| Output Voltage | 120/240V |
| Output Amps | 58/29 |
| Output Watts | 7,000 |
| Operating Speed | 1800 RPM |
| Ignition Protected | Yes |
| Exhaust Dia. | 2.0" |
| Raw Water Dia. | 3/4" |
| Fuel Line Dia. | 5/16" |
| Return Line Dia. | 3/16" |
| Warranty | 5 Year Limited Warranty |
What's Included
-
-
- 1 x Phasor K3-7.0pmg Diesel Marine Generator
- 1 x Duffle Bag With Phasor Marine Logo
- 1 x Capacitor
- 1 x 10 Micron Element - Racor Fuel Filter Separator
- 1 x Oil Pressure Switch w/Plug
- 1 x Temp Switch
- 1 x 1/4 NPT 5/16 x 1 Zinc
- 1 x Impeller LP1-2 for Oberdorfer Pump
- 1 x Belt RWP
- 1 x Belt, LP1-3.5
- 2 x LP1 HE Cap rubber
- 2 x LP1 HE Neo Washer
-
Frequently Asked Questions About Phasor K3-7.0pmg 7.0 kW Marine Generator 120/240V
What is the rated output of this generator?
This generator is rated at 7.0 kW at 60 Hz and 5.5 kW at 50 Hz. The provided specifications also list 120/240V output, 58/29 amps, and 7,000 watts.
Which engine does the Phasor K3-7.0pmg use?
This model uses a Kubota D902-E4B diesel engine. The data also confirms a three-cylinder layout and 54.8 cubic inch displacement.
Does this model include a safety shutdown system?
Yes. The stated features include a safety shutdown system for high coolant temperature or low lube oil pressure. That is one of the clearly confirmed protective features listed for this generator.
What spare parts are included with the product?
The included spare parts kit lists a capacitor, 10 micron Racor fuel filter separator element, oil pressure switch with plug, temp switch, zinc, impeller, belts, and LP1 HE cap and washer components. A duffle bag with Phasor Marine logo is also included in the listed package contents.
