CTM CT-6 6000 BTU Marine Air Conditioner 115V
$1,253.00
CTM CT-6 6000 BTU Marine Air Conditioner 115V is a self-contained marine AC unit with 50/60Hz operation, reverse cycle heating, a high-velocity turbo blower, and corrosion-resistant construction. It is designed for compact spaces and supports compatibility with several major marine A/C control platforms.
Overview CTM CT-6 6000 BTU Marine Air Conditioner 115V
CTM CT-6 6000 BTU Marine Air Conditioner 115V is a self-contained marine climate control unit built for 50/60Hz operation and designed to deliver quiet, efficient cooling with the added benefit of reverse cycle heating. This model combines a compact footprint with corrosion-resistant materials that are suited to demanding marine environments, including titanium circulating coils, stainless steel bolts, and a stainless steel structural pan with an ABS tray.
For buyers replacing an older onboard air conditioning system, the CT-6 is positioned as a drop-in replacement for major marine A/C brands including Dometic, Webasto, Cruisair, Marine Air, and Mermaid Air. It is also stated to be compatible with Dometic, Cruisair, Marine Air, and Micro Air controls, thermostats, and cables, which can simplify replacement planning when matching existing onboard components.
Key Features of CTM CT-6 6000 BTU Marine Air Conditioner 115V
- 6,000 BTU cooling capacity for small-space marine air conditioning applications.
- 100-120V, 50-60Hz electrical range for flexible marine power compatibility.
- Reverse cycle heating provides both cooling and heating capability in one unit.
- High-velocity rotatable turbo blower supports faster air distribution, with rotation of less than 250 degrees.
- Titanium condenser coil is described as highly corrosion-resistant for seawater-cooled operation.
- Stainless steel frame base, bolts, and structural pan help resist rust in marine conditions.
- ABS insulated tray adds durability and corrosion resistance.
- Universal board supports compatibility with several OEM-style controllers and the TSEP temperature sensor.
- Control boards, temperature sensors, and cables are made in the United States under strict quality standards.
- Backed by a 2-year warranty.
Applications
This model is suitable for buyers looking for a compact marine air conditioner for new installations or as a replacement unit in an existing onboard system. Its compact design and 6,000 BTU capacity make it a practical option where space is limited and a smaller-capacity unit is needed.
It can also appeal to owners who want to reuse compatible controls, thermostats, and cables from supported marine A/C platforms rather than changing the full control setup. For boats that need both cooling and occasional onboard heating, the reverse cycle function adds extra versatility.
Why Choose This Marine Air Conditioner
The CTM CT-6 stands out for buyers who want clear model-specific details rather than generic claims. This exact variant combines 6,000 BTU capacity, 115V operation, 50/60Hz compatibility, reverse cycle heating, and a turbo blower in a compact package with marine-focused materials such as titanium and stainless steel. It also offers a practical replacement path for several established marine A/C control ecosystems, which can be important when updating an existing system without fully changing onboard controls. The included 2-year warranty adds another verified point of buying confidence.
Product Specifications
| Feature | Details |
|---|---|
| Brand | CTM |
| Model | CT-6 |
| Cooling Capacity | 6,000 BTU |
| Voltage | 100-120 V |
| Frequency | 50-60 Hz |
| Refrigerant Type | R410A |
| Current Consumption Cool / Heat | 4.5 A / 5.6 A |
| Starting Amps | 20 A |
| Locked Rotor Amps | 35 A |
| Breaker Size | 15 A |
| Blower Airflow | 271 CFM |
| Blower Speed | 1980 RPM |
| High Velocity Blower | Yes |
| Minimum Supply Duct Size | 4 in / 102 mm |
| Seawater Inlet Connection | 5/8 in / 16 mm |
| Suggested Water Flow | 250 GPH |
| Net Weight | 41 lbs / 19 kg |
| Warranty | 2-Year |
What's Included
- CTM CT-6 6,000 BTU marine air conditioner unit
Frequently Asked Questions About CTM CT-6 6000 BTU Marine Air Conditioner 115V
Does this model provide heating as well as cooling?
Yes. The product data states that this unit includes reverse cycle heating, so it can provide cooling and heating. The listed current consumption is 4.5 A in cooling mode and 5.6 A in heating mode.
Can the CTM CT-6 be used as a replacement for another marine A/C brand?
The product information describes it as a drop-in replacement for major marine A/C brands including Dometic, Webasto, Cruisair, Marine Air, and Mermaid Air. It is also stated to be compatible with Dometic, Cruisair, Marine Air, and Micro Air controls, thermostats, and cables. Exact fitment dimensions are not provided, so the physical installation should still be verified before purchase.
What are the key electrical requirements for this unit?
This model operates on 100-120 V and 50-60 Hz power. It has a listed breaker size of 15 A, starting amps of 20 A, and locked rotor amps of 35 A. Those figures are useful when checking onboard electrical capacity for installation or replacement planning.
Is the CTM Touch display included with the unit?
The provided data says the CT unit is compatible with the CTM Touch display, which is described as a 2.5-inch color display with programmable parameters and operational features. However, the information provided does not explicitly confirm that the display is included in the package. Based on the available data, the unit itself is the only clearly confirmed included item.
