Webasto FCF Classic 16000 BTU Marine Air Conditioner 115V
$1,165.00
Webasto FCF Classic 16000 BTU Marine Air Conditioner 115V is a self-contained unit with reverse cycle heating, digital control, and a high-velocity 360° rotatable blower. Built for retrofit-friendly marine installation, it also features an ultra-silent compressor, corrosion-resistant construction, and a replaceable air filter.
Overview Webasto FCF Classic 16000 BTU Marine Air Conditioner 115V
Webasto FCF Classic 16000 BTU Marine Air Conditioner 115V is a self-contained marine climate control unit built for compact installation, efficient cooling, and reverse cycle heating. This 16,000 BTU model uses an ultra-silent balanced compressor to reduce vibration and noise while delivering practical onboard temperature control. It includes a digital control panel, remote control, and a remote mount electrical box, making it a well-equipped option for retrofit projects or new marine HVAC installations.
The unit is designed with a baked-on enamel finish, gold-anodized evaporators, a one-piece stainless steel chassis, and a corrosion-free stainless steel condensation tray with extra depth for added protection. A replaceable air filter supports cleaner airflow, while the multi-inlet port evaporator and high-velocity 3-speed 360° rotatable blower help direct air where it is needed. For owners replacing a Dometic ECD16k 115V unit, this model is also noted as a good replacement option.
Key Features of Webasto FCF Classic 16000 BTU Marine Air Conditioner 115V
- 16,000 BTU cooling capacity for marine cabin climate control.
- 115V / 60Hz operation with a rated current of 11A.
- Reverse cycle heating adds cold-weather functionality.
- Ultra-silent compressor helps minimize onboard noise and vibration.
- High-velocity 3-speed 360° rotatable blower supports flexible airflow direction.
- Replaceable air filter helps maintain cleaner air circulation.
- Baked-on enamel finish and gold-anodized evaporators support corrosion resistance.
- One-piece stainless steel chassis and corrosion-free condensation tray add durability in marine environments.
- Digital control with bezel and remote control are included.
- Good replacement option for Dometic ECD16k 115V systems.
Applications
This model is suited to marine installations where a 16,000 BTU self-contained air conditioner with 115V power is required. It is a practical choice for retrofit work thanks to its compact format, included controls, and replacement compatibility notes for Dometic ECD16k 115V applications. Buyers planning a replacement should review the ducting and water connection differences noted for installation.
Why Choose This Marine Air Conditioner
The FCF Classic 16000 stands out for buyers who want a clearly specified 115V marine air conditioner with reverse cycle heating, included digital controls, and corrosion-resistant construction. It combines a quiet low-vibration compressor, a flexible 360° blower, and verified installation details that are useful when replacing a Dometic ECD16k unit. With a 2-year warranty and a complete included component set, it offers solid product clarity for marine HVAC replacement or upgrade planning.
Product Specifications
| Feature | Details |
|---|---|
| Brand | Webasto |
| Model | FCF Classic 16000 |
| Part Number | FCF0016000GS |
| System Type | Self-Contained |
| Cooling Capacity | 16,000 BTU/h |
| Voltage | 115V |
| Frequency | 60Hz |
| Rated Current | 11A |
| Refrigerant | R410A |
| Cycle Type | Reverse cycle heating |
| Minimum Supply Air | 60 in² (387 cm²) |
| Minimum Return Air | 140 in² (903 cm²) |
| Blower Output | 505 cfm (858 m³/h) |
| Ducting Collar Diameter | 5 in (127 mm) |
| Seawater Inlet / Outlet | 3/4 in (19 mm); 5/8" adapter included |
| Drain Pan Outlet | 5/8 in (15.9 mm) |
| Dimensions | 17.7" L x 17.9" D x 13" H |
| Weight | 76 lb / 33 kg |
| Warranty | 2-Year Warranty |
What's Included
- Webasto FCF Classic 16000 BTU Marine Air Conditioner - 115V
- 5" ducting collar
- High-velocity 360° rotatable blower
- Remote mount electrical box
- Digital control with bezel
- Air filter
- Remote control
- 5/8" to 3/4" adapter for water connection
- R410A refrigerant
Frequently Asked Questions About Webasto FCF Classic 16000 BTU Marine Air Conditioner 115V
Does this unit provide both cooling and heating?
Yes. This model includes reverse cycle heating in addition to its 16,000 BTU cooling capacity. That makes it suitable for buyers who want marine climate control for both warm and cooler conditions.
What comes in the box with this Webasto FCF Classic unit?
The package includes the air conditioner, 5" ducting collar, high-velocity 360° rotatable blower, remote mount electrical box, digital control with bezel, air filter, remote control, R410A refrigerant, and a 5/8" to 3/4" adapter for water connection. These are the items specifically listed in the provided product data.
Can this replace a Dometic ECD16k 115V system?
Yes, it is described as a good replacement option for the Dometic ECD16k 115V. Installation differences to note include 4" and 5" ducting on the Webasto unit instead of 5" and 6" on the Dometic, a larger condenser connection requiring the included 5/8" to 3/4" adapter, and the need to replace the controller and cable with the included Webasto parts.
What technical requirements should I check before installation?
This unit is rated for 115V, 60Hz power and draws 11A. It uses a 5" ducting collar, requires a minimum supply air area of 60 in² and return air area of 140 in², and has 3/4" seawater inlet/outlet connections with a 5/8" adapter included.
