Webasto S10 BlueCool S Series 10000 BTU Marine Air Conditioner 230V
$1,437.00
Webasto S10 BlueCool S Series 10000 BTU Marine Air Conditioner 230V is a self-contained unit with reverse cycle heating, MyTouch digital control, and a 270° rotatable blower. Built for compact marine installation, it offers 50/60 Hz compatibility, corrosion-protected construction, and USB diagnosis support.
Overview Webasto S10 BlueCool S Series 10000 BTU Marine Air Conditioner 230V
Webasto S10 BlueCool S Series 10000 BTU Marine Air Conditioner 230V is a self-contained marine air conditioning unit with reverse cycle heating, MyTouch digital control, and 50/60 Hz compatibility for worldwide usage. This compact S Series model is built for quiet, powerful onboard cooling while keeping all major components on one tray for a practical installation layout. The included display, remote mount electrical box, and 270° rotatable blower give buyers a clearly defined package for marine climate control.
The unit is epoxy-painted and fitted with a stainless steel drain pan for corrosion protection in marine environments. It also features a thermally insulated stainless steel tray, updated electronics with USB diagnosis, and a multi-point injection evaporator intended to improve efficiency. Webasto states that S10 BlueCool S Series self-contained air conditioners are suitable for boats with up to three cabins.
Key Features of Webasto S10 BlueCool S Series 10000 BTU Marine Air Conditioner 230V
- 10,000 BTU/h cooling capacity with reverse cycle heating integrated.
- 230V operation with 50/60 Hz compatibility for worldwide usage.
- MyTouch digital control with bezel is included.
- High-velocity 270° rotatable blower supports flexible airflow direction.
- Epoxy-painted housing and stainless steel drain pan support corrosion protection.
- Mounted on an extra-deep, thermally insulated stainless steel tray.
- New electronics with USB diagnosis support BlueCool Expert Tool connection.
- Multi-point injection evaporator is designed for higher unit efficiency.
- Recommended seawater pump is WB350.
- Soft start devices are available as an option.
Applications
This model is suitable for marine installations where a 230V self-contained unit with 10,000 BTU cooling and reverse cycle heating is required. It is specifically described as suitable for boats with up to three cabins, making it a practical choice for cabin-focused cooling and heating layouts. Its compact format and one-tray component arrangement also support straightforward onboard installation planning.
Why Choose This Marine Air Conditioner
The BlueCool S10 is a strong option for buyers who want a clearly specified self-contained marine air conditioner with included MyTouch control, reverse cycle heating, and 50/60 Hz compatibility. Its 270° blower, USB diagnosis capability, corrosion-protected construction, and defined seawater pump recommendation make it easier to assess for installation and servicing. With a 2-year warranty and verified technical data, it offers solid product clarity for marine HVAC replacement or upgrade work.
Product Specifications
| Feature | Details |
|---|---|
| Brand | Webasto |
| Model | S10 BlueCool S Series |
| Part Number | WBCL120002E |
| System Type | Self-Contained |
| Cooling Capacity | 10,000 BTU/h |
| Cooling Capacity (kW) | 2.9 |
| Heating | Reverse cycle integrated |
| Voltage | 230V |
| Frequency | 50/60Hz |
| Current Draw Running (50 Hz) | 2.6 - 4.0A |
| Start Max Peak Current (50 Hz) | 27A |
| Air Flow (Free Blowing) | 400 m3/h (235 cfm) |
| Sea Water Connection | 19 mm / 3/4 in |
| Minimum Sea Water Flow at 50 Hz | 10 l/min |
| Minimum Sea Water Flow at 60 Hz | 12 l/min |
| Recommended Seawater Pump | WB350 |
| Blower Connection | 100 mm / 4 in |
| Unit Dimensions | 475 x 330 x 310 mm (15.7 x 12.6 x 12.0 in) |
| Weight Core Unit | 22 kg / 49 lb |
| Warranty | 2-Year Warranty |
What's Included
- Webasto S10 BlueCool S Series 10000 BTU Marine Air Conditioner - 230V
- 4" ducting collar
- High-velocity 270° rotatable blower
- Remote mount electrical box
- MyTouch digital control with bezel
- Air filter
- R410A refrigerant
Frequently Asked Questions About Webasto S10 BlueCool S Series 10000 BTU Marine Air Conditioner 230V
Does this unit include both cooling and heating?
Yes. The technical data states 10,000 BTU/h cooling capacity and confirms that heating via reverse cycle is integrated. That means the unit provides both cooling and heating in one self-contained system.
What control display is included with this model?
This unit includes the BlueCool MyTouch display with bezel. The product data describes it as a full-color, high-resolution 2.4-inch interactive touch screen with multiple customization options and protected access to system configuration parameters.
Is this unit suitable for worldwide usage?
Yes. The product description states that it is fully 50/60 Hz compatible and suitable for worldwide usage. That makes it more flexible for installations that require 230V operation across different frequency standards.
What installation-related specifications should I check before ordering?
Check the 230V power requirement, the 3/4-inch sea water connection, and the minimum sea water flow of 10 l/min at 50 Hz or 12 l/min at 60 Hz. You should also confirm the 4-inch blower connection, unit dimensions of 15.7 x 12.6 x 12.0 inches, and the recommended WB350 seawater pump.
